W5500 Ethernet Shield is an IoT panel, you can receive and send data from anywhere in the world with an internet connection by it, It included SD slot enables applications that require storing large amounts of data, like IoT data logging. Thanks to a lowered RJ45 port, you can flexibly add most of shields on top of this Ethernet Shield.
Features:
- High speed Ethernet controller W5500
- SPI interface
- 32 Kbytes inner buffer
- Minimal RJ45 Ethernet port
- Supports Hardwired TCP/IP Protocols : TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE
- Supports 8 independent sockets simultaneously
- Handy SD card function
- Grove ports for I2C and UART preformed
- Low power consumption
Specification:
- RJ45: Ethernet Port;
- IC W5500: a hardwired TCP/IP Ethernet Controller;
- Reset Button: Reset Ethernet shield ;
- SD Card Socket: support Micro SD card in FAT16 or FAT32; maximum storage is 2GB.
- I2C Interface
- UART Interface
Documents:
Please visit wiki page for more info about this product.
